SAUTER 289-102 Mechanical force gauge till 5N

SAUTER 289-104 Mechanical force gauge till 10N

SAUTER
289-100

Mechanical force measurement with quality spring for long service life

TECHNICAL DATA

Measuring range force [Max] (N) 10 N
Readability force [d] (N) 0,1 N; 0,5 N
Tolerance (% of [Max]) 0,3%
Load support (tensile force) Hook
Length unloaded (l [Min]) 230 mm
Length loaded (l [Max]) 335 mm
Housing diameter (Ø) 12,5 mm
Dimensions completely mounted (W×D×H) 230×12,2×12,2 mm
Material housing plastic
Certificate : without Certificate
Hurry! only 5 items left in stock.
€82.80
€92.00
Save 10%
Tax excluded
Quantity

Add to Compare
Add to Wishlist

The very best price/performance ratio thanks to the transparent plastic housing, ideal for schools and educational institutions

Newton scale: The SAUTER 289 range can display the results in Newtons instead of in grammes, specifically for measuring tensile forces

Double scale: For fast or precise recording of the measurement result

High precision: Backlash-free spring bearing with integrated tare screw for highly-precise adjustment

Non-fatigue stainless steel spring

Abrasion-resistant, colour precision scale with high resolution

Thanks to the rotating inner tube, the scale is always easy to read

The bracket which is delivered as standard can easily be swapped for another suspension device, so that the system can be individually adapted to the items being weighed
