  SAUTER FK



  Force gauge SAUTER FK

  Robust Push/Pull force gauge SAUTER FK for simple measurement

  • Turnable display: automatic direction identification
  • Secure operability due to ergonomic design
  • Real time or Peak Hold Mode to observe transcients or capture peaks
  • Selectable measuring units: N, lb, kg, oz
  • Auto-Power-Off
  • With one of the two optional attachments for tensile strength testing, the SAUTER FK can become a tensiometer for testing the material tension characteristics of cables, threads, wires, twine etc. (see accessories)
  • Standard attachments: as shown below, extension rod: 90 mm
  • Can be mounted on all SAUTER test stands

  Technical data

  • Precision: 0,5 % of [Max]
  • Internal measuring frequency: 1000 Hz
  • Overload protection: 200 % of [Max]
  • Dimensions W×D×H 195×82×35 mm
  • Thread: M8
  • Ready for use: Batteries included, 6×1,5 V AA
  • Net weight approx. 0,72 kg

  Accessories SAUTER FK

  With one of the two optional attachments for tensile strength testing, the SAUTER FK can become a tensiometer for testing the material tension characteristics of cables, threads, wires, twine etc. (up to ∅ 5 mm): Illustration shows accessories SAUTER FK-A02

  Tensiometer attachment with Safe-insert  function: Pull and release to insert the running cable in between the rolls, for tensile strength testing up to 250 N, aluminium attachment, rolls can be adjusted inwards, SAUTER FK-A01

  Tensiometer kit for high-capacity tensile strength testing up to 1000 N, steel  attachment and steel rolls, rolls cannot be adjusted, SAUTER FK-A02

  Standard attachments, as standard, set can be reordered, SAUTER AC 430

•

  SAUTER FC



  Force gauge SAUTER FC

  Compact force-measuring device

  • Turnable display with backlight
  • Real time or Peak Hold Mode to observe transcients or capture peaks
  • Metal housing for durable usage in harsh environmental conditions
  • Capacity display: A bar lights up to show how much of the measuring range is still available
  • Measuring with tolerance range (limit-setting function): Upper and lower limiting can be programmed between 10 and 100 % of [Max], in pull and push direction. The process is supported by an acoustic and visual signal
  • Safety: If loads exceed 110 % of the measuring range, the device will give clear acoustic and visual signals
  • Internal memory for up to 1000 measurements
  • USB data interfaces as standard
  • Data interface RS-232 (only for connection to the printer)
  • Selectable: AUTO-OFF function or permanent operation
  • Delivered in a hard carrying case
  • Selectable measuring units: N, kg, oz, lb
  • Standard attachments: as shown below, extension rod: 90 mm
  • Can be mounted on all SAUTER test stands (with adapter plate)

  Features SAUTER FC

  • Adjusting program (CAL): For quick setting of the balance's accuracy. External adjusting weight required.
  • Peak hold function: capturing a peak value within a measuring process.
  • Push and Pull: the measuring device can capture tension and compression forces.
  • Memory: Balance contains memories, e.g. for  tare weights, weighing data, item data,  PLU etc.
  • Data interface RS-232: To connect the balance to a printer, PC or network
  • USB data interface: To connect the balance to a printer, PC or other peripherals.
  • GLP/ISO record keeping of weighing data with date, time and identification-no. Only with printers from KERN.
  • Weighing units: Can be switched to e.g. nonmetric units at the touch of a key. See balance model.
  • Weighing with tolerance range: Upper and lower limiting can be programmed individually, e. g. sorting and portioning.
  • Resets the display to “0”
  • Rechargeable battery pack: rechargeable set
  • Mains adapter: 100-230V/50-60Hz EU. On request GB or USA version.
  • 2 years warranty

  Option

  • PC software: to transfer the measurements from the device to a PC.
  • ISO calibration possible.

  Technical data SAUTER FC

  • Measuring precision: 0,3 % of [Max]
  • Transmission rate to PC: up to 200 measured values/second
  • Overload protection: 150 % of [Max]
  • Overall dimensions W×D×H 145×73×34 mm
  • Thread: M6
  • Rechargeable battery pack integrated,  standard, operating time up to 20 h without backlight, charging time approx. 4 h
  • Net weight approx. 0,94 kg

  Accessories SAUTER FC

  • Data transfer software with graphic display of the measurement process, Force-time, SAUTER AFH FAST
  • Force-displacement only in combination with SAUTER LB, SAUTER AFH FD
  • Standard attachments - AC 43
  • RS-232/PC connection cable to connect models from the SAUTER FC range to a printer - FC-A01
  • Standard attachments for Force gauges 10 - 500 N, 6 items (M6-Thread) - AC 43
  • M10 External thread, M6 Threaded hole - AFM 05
  • M10 External thread, M6 Threaded hole - AFM 07
  • M6 Threaded hole, M5 External thread - AFM 102
  • M12 Threaded hole, M6 Threaded hole - AFM 15

•

  SAUTER FH-S



  SAUTER FH Force Gauges

  Precision at Your Fingertips

  Introducing the SAUTER FH series of force gauges, the ultimate solution for precise tension and compression testing. Whether you're working in quality control, manufacturing, research, or education, the SAUTER FH force gauges are designed to deliver reliable, accurate results with ease.

  Key Features

  Integrated Measuring Cell: The SAUTER FH force gauges come equipped with a high-precision, integrated measuring cell that ensures accurate readings for both tension and compression tests. This feature eliminates the need for additional components, providing a compact and efficient solution for all your measurement needs.

  RS-232 Data Interface: Data management is streamlined with the built-in RS-232 interface, allowing seamless communication with PCs and other devices. Easily transfer and analyze data to enhance your testing processes and documentation.

  High Accuracy: Achieve consistent and precise measurements with a high degree of accuracy. The SAUTER FH force gauges are meticulously calibrated to deliver reliable results you can trust.

  User-Friendly Design: The ergonomic design ensures comfortable handling during prolonged use. The intuitive interface makes it simple to operate, even for those new to force measurement.

  Versatile Applications: Ideal for a wide range of applications including material testing, component testing, and product quality assessments. The SAUTER FH series is perfect for use in laboratories, production lines, and educational institutions.

  Robust Construction: Built to last, the SAUTER FH force gauges feature a durable construction that can withstand rigorous testing environments. Enjoy long-lasting performance and dependability.

  LCD Display: The clear, easy-to-read LCD display provides real-time results, ensuring you have the information you need at a glance. Backlighting ensures visibility even in low-light conditions.

  Measurement Range: Available in multiple measurement ranges to suit your specific requirements. Choose the model that best fits your testing needs.

  Technical Specifications

  • Measurement Accuracy: ±0.5% of full scale
  • Measurement Units: N, kg, lb (selectable)
  • Display: Large backlit LCD
  • Overload Protection: 150% of capacity
  • Power Supply: Rechargeable battery or AC adapter
  • Data Output: RS-232 interface for data transfer
  • Operating Temperature: 10°C to 40°C

  Applications

  • Quality Control: Ensure product consistency and reliability with precise force measurements.
  • Manufacturing: Monitor and test components during production to maintain high standards.
  • Research & Development: Conduct comprehensive tests to innovate and improve product designs.
  • Education: Equip students and professionals with the tools needed for accurate force measurement in various scientific and engineering disciplines.

  Invest in the SAUTER FH force gauges for unmatched accuracy, reliability, and ease of use in your tension and compression testing. Elevate your testing capabilities with a tool designed for excellence.

•

  SAUTER FL



  Force gauge SAUTER FL

  Premium force measuring instrument with graphic-assisted display and integrated measuring cell

  • Turnable display with backlight
  • Real time or Peak Hold Mode to observe transcients or capture peaks
  • Metal housing for durable usage in harsh environmental conditions
  • Can be mounted on all SAUTER test stands
  • Capacity display: A bar lights up to show how much of the measuring range is still available
  • Measuring with tolerance range (limit-setting function): Upper and lower limiting can be programmed, in pull and push direction. The process is supported by a visual signal
  • Internal memory for up to 500 measurements
  • Continuous analogue output: Linear voltage signal in relation to the load (-2 – +2 V)
  • Standard attachments: as shown below
  • Selectable measuring units: N, kN, kg, oz, lb
  • Delivered in a hard carrying case

  Technical data SAUTER FL

  • Transfer rate to PC: approx. 25 measured values per second
  • Measuring precision: 0,2 % of [Max]
  • Overload protection: 120 % of [Max]
  • Overall dimensions W×D×H 175×75×30 mm
  • Thread: M6
  • Rechargeable battery pack integrated,  standard, operating time up to 10 h without backlight, charging time approx. 8 h
  • Net weight approx. 0,5 kg

  Accessories for SAUTER FL

  • Plug-In for data transfer of measuring data from the measuring instrument and transfer to a PC, e.g. in Microsoft Excel®,  SAUTER AFI-1.0
  • Data transfer software with graphic  display of the measurement process,  SAUTER AFH FAST
  • Force-displacement only in combination  with SAUTER LD, SAUTER AFH LD
  • Force-displacement only in combination  with SAUTER LB, SAUTER AFH FD
  • USB cable, as standard, can be reordered, SAUTER FL-A01
  • Standard attachments for Force gauges 10 - 500 N, 6 items (M6-Thread) - AC 43
  • Stainless steel handle bar with rubber grip for safe handling, 1 piece - AFH 04 € 105,00 *
  • RS232 adapter cable - FL-A04 € 50,00 *
  • M10 External thread, M6 Threaded hole - AFM 05
  • M10 External thread, M6 Threaded hole - AFM 07
  • M6 Threaded hole, M5 External thread - AFM 102
  • M12 Threaded hole, M6 Threaded hole - AFM 15

  Features SAUTER FL

  • Peak hold function: capturing a peak value within a measuring process.
  • Push and Pull: the measuring device can capture tension and compression forces.
  • Memory: Balance contains memories, e.g. for  tare weights, weighing data, item data,  PLU etc.
  • Data interface RS-232: To connect the balance to a printer, PC or network
  • USB data interface: To connect the balance to a printer, PC or other peripherals.
  • Analog Data Interface
  • GLP/ISO record keeping of weighing data with date, time and identification-no. Only with printers from KERN.
  • Weighing units: Can be switched to e.g. nonmetric units at the touch of a key. See balance model.
  • Measuring with tolerance range  (limit-setting function): Upper and lower limiting can be programmed individually. The process is supported by an audible or visual signal
  • Rechargeable battery pack: rechargeable set
  • Mains adapter: 100-230V/50-60Hz in standard version for Germany. On request GB or USA version.
  • 2 years warranty

  ALL MODELS SAUTER FL

  Model	Measuring capacity [Max] N	Readability [d] N	Option Calibration Certificate (Tension)	Option Calibration Certificate (Compression)	Option Calibration Certificate (Tension + Comp)
  FL 5	5	0,002	-	-	-
  FL 10	10	0,005	1	1	1
  FL 20	25	0,01	1	1	1
  FL 50	50	0,02	1	1	1
  FL 100	100	0,05	1	1	1
  FL 200	250	0,1	1	1	1
  FL 500	500	0,2	1	1	1
  FL 1K	1000	0,5	1	1	1

•

  SAUTER FS

  SAUTER FS Premium force gauge

  with integrated measuring cell (optional) and connection possibility for up to 4 external measuring cells

  Use with integrated measuring cell

  The SAUTER FS premium force gauge has an integrated measuring cell for tensile and compressive force applications. Whether mobile for rapid testing or stationary integrated into a test stand or production line, the multifunction display allows all the values recorded to be read off at a glance in real time. Via the integrated interface, the data can be sent to a PC or laptop for further processing.

  Use with external measuring cells

  The SAUTER FS premium force gauge is compatible with all SAUTER strain gauge measuring cells. Up to 4 external measuring cells can be connected simultaneously. If all available external measuring channels are used, the internal measuring cell is deactivated as long as an external measuring cell is connected.

  • 3.5" touch screen
  • Standard version with 2 or 4 measuring channels for external force sensors (subsequently expandable from 2 to 4)
  • An internal measuring cell possible (is deactivated if an external measuring cell is plugged into slot 1)
  • Suitable for 4-wire and 6-wire sensors with strain gauges
  • Two-point adjustment with weights or numerical adjustment is possible
  • The specific data of an external sensor are stored directly in the connector
  • USB interface for programming, data transfer and power supply
  • Integrated SD card memory
  • Adjustable SI units: kg, N, kN, Nm, kNm
  • Tolerance function
  • TRACK function for continuous display of the measurement
  • Peak value measurement
  • Mountable on SAUTER test benches
  • Simultaneous measurement on up to four channels. External sensors with sensor data memory, optionally available
  • Compact force-measuring device with internal measuring cell (up to max. 500 N) for rapid, mobile force measurement
  • Delivery in high-quality and robust system case (systainer® T-LOC) including plug-in power supply and USB cable type C
  • Measurement of forces in different tensile or compressive directions possible with only one measuring device

  Features SAUTER FS

  • Peak hold function: capturing a peak value within a measuring process.
  • Scan mode: continuous capture and display of measurements.
  • Push and Pull: the measuring device can capture tension and compression forces.
  • Memory: Balance contains memories, e.g. for  tare weights, weighing data, item data,  PLU etc.
  • USB data interface: To connect the balance to a printer, PC or other peripherals.
  • KERN Communication Protocol (KCP)
  • Weighing with tolerance range: Upper and lower limiting can be programmed individually, e. g. sorting and portioning.
  • ZERO: Resets the display to “0”
  • Rechargeable battery pack: rechargeable set



  Can be mounted on all SAUTER test benches and the manual test bench  SAUTER TVL-XS



  Simultaneous measurement on up to four channels. External sensors with sensor data memory optionally available



  Compact force gauge with internal measuring cell (up to max. 500 N) for fast and mobile force measurements. Illustration shows optional accessories SAUTER AE 500 screw tension clamp



  Measurement of forces in different tensile or compressive directions possible with only one measuring device

  Technical data SAUTER FS

  • High resolution: up to 10000 points per measurement channel
  • Storage of measured values as well as their transmission to the interface with up to 1000 Hz per measuring channel
  • Measurement accuracy:
    • - with internal measuring cell: 0.1 % of [Max]
    • - with external measuring cell: among other things from the measuring cells used
  • Overall dimensions W×D×H 71×31×180 mm
  • Overload protection: 150 % of [Max] with internal measuring cell
  • Thread on load receptor: M6 (outside)
  • Battery operation internal, standard, operating time up to 8 h, Charging time approx. 8 h
  • External mains adapter, for connection to the USB-C socket, standard
  • Net weight approx. 0,4 kg

  Model	Measuring range internal measuring cell [Max] N	Readability internal measuring cell [d] N	Internal measuring cell	Number measurement channels
  FS 2	-	-	-	2
  FS 2-20	20	0,005	yes	2
  FS 2-50	50	0,01	yes	2
  FS 2-100	100	0,02	yes	2
  FS 2-200	200	0,05	yes	2
  FS 2-500	500	0,1	yes	2
  FS 4	-	-	-	4
  FS 4-20	20	0,005	yes	4
  FS 4-50	50	0,01	yes	4
  FS 4-100	100	0,02	yes	4
  FS 4-200	200	0,05	yes	4
  FS 4-500	500	0,1	yes	4
