• CE and RoHS compliant
• Accuracy class L
• protection against dust and water splashes IP65 (in accordance with EN 60529)
• Aluminium, anodised
• Suitable for price-computing scales, bench scales, platform scales, etc.
• Maximum platform size 200×200 mm
• 4-wire connection
• Nominal sensitivity: 0,9 mV/V

4-wire “S” measuring cell made of nickel-plated steel for force and mass measurement

Technical Data

Measuring System

Measuring range torque [Max] 1 Nm

IP protection - complete device IP65

characteristic value - nominal 1,5 mV/V

characteristic value - variance 0,5 mV/V

connection 4-wire

Input resistance - nominal 380 Ω

Input resistance - variance 10 Ω

Output resistance - nominal 350 Ω

Output resistance - variance 3 Ω

Recommended exitation voltage [Min] 9 V

Recommended exitation voltage [Max] 12 V

Isolation resistance - [Min] 5000 MΩ

Combined error 0,5% Construction

Material steel

Cable length 2 m

Net weight approx. 0,40 kg

Measuring System

Measuring range torque [Max] 5 Nm

characteristic value - nominal 1,5 mV/V

characteristic value - variance 0,2 mV/V

connection 4-wire

Input resistance - nominal 380 Ω

Input resistance - variance 10 Ω

Output resistance - nominal 350 Ω

Output resistance - variance 3 Ω

Recommended exitation voltage [Min] 9 V

Recommended exitation voltage [Max] 12 V

Isolation resistance - [Min] 5000 MΩ

Combined error 0,5% Construction

Material steel

Cable length 2 m

Net weight approx. 0,40 kg

6-wire "S" measuring cell made of nickel-plated steel for force and mass measurement

Technical Data SAUTER CS 50-3Q1

Universal weighing platforms for flexible connection in process chains

Technical Data KERN KDP 300-3

The robust aluminium cast housing maintains the stability, protects the weighing technology elements and is robust enough to cope with everyday use with protection against dust and water splashes IP65

• Prepared for 4-wire and 6-wire measuring cells
• Models available for 2, 4, 6 or 8 load cells

Option

4-wire “S” measuring cell made of nickel-plated steel for force and mass measurement

Technical Data

Measuring System

Measuring range torque [Max] 10 Nm

IP protection - complete device IP65

characteristic value - nominal 1,5 mV/V

characteristic value - variance 0,5 mV/V

connection 4-wire

Input resistance - nominal 380 Ω

Input resistance - variance 10 Ω

Output resistance - nominal 350 Ω

Output resistance - variance 3 Ω

Recommended exitation voltage [Min] 9 V

Recommended exitation voltage [Max] 12 V

Isolation resistance - [Min] 5000 MΩ

Combined error 0,5% Construction

Material steel

Cable length 2 m

Net weight approx. 0,40 kg

Measuring System

Measuring range torque [Max] 10 Nm

characteristic value - nominal 1,2 mV/V

characteristic value - variance 0,2 mV/V

connection 4-wire

Input resistance - nominal 380 Ω

Input resistance - variance 10 Ω

Output resistance - nominal 350 Ω

Output resistance - variance 3 Ω

Recommended exitation voltage [Min] 9 V

Recommended exitation voltage [Max] 12 V

Isolation resistance - [Min] 5000 MΩ

Combined error 0,5% Construction

Material steel

Cable length 2 m

Net weight approx. 0,40 kg

6-wire "S" measuring cell made of nickel-plated steel for force and mass measurement

Technical Data SAUTER CS 100-3Q1

The robust aluminium cast housing maintains the stability, protects the weighing technology elements and is robust enough to cope with everyday use with protection against dust and water splashes IP65

• Prepared for 4-wire and 6-wire measuring cells
• Models available for 2, 4, 6 or 8 load cells

4-wire “S” measuring cell made of nickel-plated steel for force and mass measurement

Technical Data

Measuring System

Measuring range torque [Max] 20 Nm

IP protection - complete device IP65

characteristic value - nominal 1,5 mV/V

characteristic value - variance 0,5 mV/V

connection 4-wire

Input resistance - nominal 380 Ω

Input resistance - variance 10 Ω

Output resistance - nominal 350 Ω

Output resistance - variance 3 Ω

Recommended exitation voltage [Min] 9 V

Recommended exitation voltage [Max] 12 V

Isolation resistance - [Min] 5000 MΩ

Combined error 0,5% Construction

Material steel

Cable length 2 m

Net weight approx. 0,40 kg

Measuring System

Measuring range torque [Max] 20 Nm

characteristic value - nominal 1,3 mV/V

characteristic value - variance 0,2 mV/V

connection 4-wire

Input resistance - nominal 380 Ω

Input resistance - variance 10 Ω

Output resistance - nominal 350 Ω

Output resistance - variance 3 Ω

Recommended exitation voltage [Min] 9 V

Recommended exitation voltage [Max] 12 V

Isolation resistance - [Min] 5000 MΩ

Combined error 0,5% Construction

Material steel

Cable length 2 m

Net weight approx. 0,40 kg

6-wire "S" measuring cell made of nickel-plated steel for force and mass measurement

Technical Data SAUTER CS 150-3Q1

• RoHS compliant
• protection against dust and water splashes IP65
• Area of application: Tensile and compressive applications , weight and force measurement
• Suitable for hanging scales, silo scales, force test benches and other types of balances

S measuring cells and S load cells made from stainless steel

• Combined Error: 0,050 %
• Load cell connection: 4-wire
• Nominal sensitivity: 2
• Weighing capacity [Max]: 1 kg
• Cable length: 2 m

4-wire “S” measuring cell made of nickel-plated steel for force and mass measurement

Technical Data

Measuring System

Measuring range torque [Max] 50 Nm

IP protection - complete device IP65

characteristic value - nominal 1,5 mV/V

characteristic value - variance 0,5 mV/V

connection 4-wire

Input resistance - nominal 380 Ω

Input resistance - variance 10 Ω

Output resistance - nominal 350 Ω

Output resistance - variance 3 Ω

Recommended exitation voltage [Min] 9 V

Recommended exitation voltage [Max] 12 V

Isolation resistance - [Min] 5000 MΩ

Combined error 0,5% Construction

Material steel

Cable length 2 m

Net weight approx. 0,40 kg

Measuring System

Measuring range torque [Max] 50 Nm

characteristic value - nominal 1,7 mV/V

characteristic value - variance 0,2 mV/V

connection 4-wire

Input resistance - nominal 380 Ω

Input resistance - variance 10 Ω

Output resistance - nominal 350 Ω

Output resistance - variance 3 Ω

Recommended exitation voltage [Min] 9 V

Recommended exitation voltage [Max] 12 V

Isolation resistance - [Min] 5000 MΩ

Combined error 0,5% Construction

Material steel

Cable length 2 m

Net weight approx. 0,40 kg
