SAUTER 289-100 Mechanical force gauge 1N
72.90 €Save 10%
81.00 €
Tax excluded
Mechanical force measurement with quality spring for long service life
TECHNICAL DATA
| Measuring range force [Max] (N) | 1 N |
| Readability force [d] (N) | 0,01 N; 0,05 N |
| Tolerance (% of [Max]) | 0,3% |
| Load support (tensile force) | Hook |
| Length unloaded (l [Min]) | 230 mm |
| Length loaded (l [Max]) | 335 mm |
| Housing diameter (Ø) | 12,2 mm |
| Dimensions completely mounted (W×D×H) | 230×12,2×12,2 mm |
| Material housing | plastic |
The very best price/performance ratio thanks to the transparent plastic housing, ideal for schools and educational institutions
Newton scale: The SAUTER 289 range can display the results in Newtons instead of in grammes, specifically for measuring tensile forces
Double scale: For fast or precise recording of the measurement result
High precision: Backlash-free spring bearing with integrated tare screw for highly-precise adjustment
Non-fatigue stainless steel spring
Abrasion-resistant, colour precision scale with high resolution
Thanks to the rotating inner tube, the scale is always easy to read
The bracket which is delivered as standard can easily be swapped for another suspension device, so that the system can be individually adapted to the items being weighed
289-100
