Ultrasonic thickness gauge SAUTER TU 80-0.01US
  • Ultrasonic thickness gauge SAUTER TU 80-0.01US
  • Ultrasonic thickness gauge SAUTER TU 80-0.01US
  • Ultrasonic thickness gauge SAUTER TU 80-0.01US
  • Ultrasonic thickness gauge SAUTER TU 80-0.01US
  • Ultrasonic thickness gauge SAUTER TU 80-0.01US

Ultrasonic thickness gauge SAUTER TU 80-0.01US

1,179.00 €Save 10%
1,310.00 €
Tax excluded

Calibration block: standard for adjusting or correcting the measuring device. Memory: Balance contains memories, e.g. for tare weights, weighing data, item data, PLU etc. Data interface RS-232: To connect the balance to a printer, PC or network Weighing with tolerance range: Upper and lower limiting can be programmed individually, e. g. sorting and portioning. Resets the display to zero Battery operation: The battery type is specified for each device. 2 years warranty

Certificate
  100% buyer protection

Guaranteed with PayPal

  100% secure shipping

Insured and with tracking

  3 year guarantee

100% full processing

  • External sensor for difficult-to-access measurements
  • Base plate for adjustment included
  • Data interface RS-232
  • Delivered in a hard carrying case
  • Scan mode (10 measurements per sec.) or single point measuring mode possible
  • Internal memory for up to 20 files (with up to 100 values per file)
  • Function to set limits, programming of Max./Min., in pull and push direction, with output of audible and optical signal. Ideal mode for efficient and accurate testing of standard parts
  • Selectable measuring units: mm, inch

Ultrasonic thickness gauge SAUTER TU 80-0.01US

  • Calibration block: standard for adjusting or correcting the measuring device.
  • Memory: Balance contains memories, e.g. for tare weights, weighing data, item data, PLU etc.
  • Data interface RS-232: To connect the balance to a printer, PC or network
  • Weighing with tolerance range: Upper and lower limiting can be programmed individually, e. g. sorting and portioning.
  • Zero setting
  • Battery operation: The battery type is specified for each device.
  • 2 years warranty

Options/Accessories

  • Software, interface cable included, SAUTER ATU-04
  • External sensor, 2,5 MHz, Ø 14 mm, for thick samples, in particular cast iron with rough upper surfaces: Measuring range 3 – 300 mm (steel), SAUTER ATU-US01
  • External sensor, 7 MHz, Ø 6 mm, for thin test materials: Measuring range 0,75 – 80 mm (steel), SAUTER ATU-US02
  • External sensor, 5 MHz, Ø 12 mm, for hot test materials: Measuring range (steel) 3 – 200 mm at temperatures of up to 300 °C, SAUTER ATB-US02
  • External sensor, 5 MHz, Ø 10 mm, SAUTER ATU-US09
  • External sensor, 5 MHz, Ø 10 mm, transducer at an angle of 90°, SAUTER ATU-US10
  • External sensor, 6 MHz, Ø 6 mm, for thin test materials: Measuring range

TU 80-0.01US

Data sheet

Measuring capacity
0,75–80 mm
Readout [d]
0,01 mm
Measuring head
7 MHz | ∅ 6 mm
Measuring frequency
1000–9999 m/sec
Net weight
345 g
Measuring units
inch mm
