KERN DAB 100-3 Moisture analyser


KERN DAB 100-3 Moisture analyser

KERN
DAB 100-3

with user-friendly graphics display and 15 memories for drying programs

  • Backlit LCD display, digit height 14 mm
    • Drying process active
    • Active heating profile
    • Active switch-off criteria
    • Previous drying time
    • Current temperature
    • Unit of the shown result, e.g. moisture [%]
    • Interim result in moisture-%
  • Halogen quartz glass heater 400 W
  • Observation window above the sample, useful during initial setting
  • Internal memory for automatic sequence of 15 complete drying processesand 5 drying processes carried out
  • The last value measured remains on the display until it is replaced by a new measurement
  • 50 sample plates included
  • Application handbook: On the internet, you will find a practical application handbook containing many examples, field reports, settings and tips for each KERN moisture analyser
Certificate : without Certificate
Hurry! only 9 items left in stock.
€1,125.00
€1,250.00
Save 10%
Tax excluded
Quantity

Add to Compare
Add to Wishlist

KERN DAB 100-3 Moisture analyser

  • Adjusting program (CAL): For quick setting of the balance's accuracy. External adjusting weight required.
  • Memory: Balance contains memories, e.g. for tare weights, weighing data, item data, PLU etc.
  • Data interface RS-232: To connect the balance to a printer, PC or network
  • GLP/ISO log: with weight, date and time. Only with KERN printers, see Accessories
  • Weighing units: Can be switched to e.g. nonmetric units at the touch of a key. See balance model.
  • Mains part: mains part integrated in the balance. 230V/50Hz Standard type D, if requested also available in standard GB, AUS or USA.
  • Strain gauge: An electrical resistor strip that is glued to an elastic deforming body made of aluminium. As the strain gauge is mechanically deformed its resistance value changes, allowing
  • 3 years warranty

Particularly user-friendly moisture analyzer with high-quality halogen quartz glass heater

TECHNICAL DATA

Weighing capacity [Max] 110 g
Readability [d] 0,001 g
Weighing system Strain gauge
Temperature [Min] (°C) 40 °C
Temperature [Max] (°C) 199 °C
Stabilization time 3 s
Units g, % Humidity, % Dry mass
Reproducibility 0,001 g
Linearity ± 0,003 g
Readability moisture [d] (%) 0,01%
Drying modes Standard drying, Rapid drying, Gentle drying
Switch-off criteria time controlled, automatic, manual
Input voltage device / power [Max] 230 V AC, 50 Hz
: DAB 100-3
Hurry! only 9 items left in stock.

Data sheet

Readout [d]
1 mg / 0,010 %
Reproducibility
1 mg / 0,010 %
Weighing plate dimensions
Ø 92 mm
Net weight
4,9 kg
Weighing range [Max]
110 g
