KERN DAB 200-3 Moisture analyser


KERN DAB 200-2 Moisture analyser 0,01g / 0,050%

KERN
DAB 200-2

Moisture analyser with user-friendly graphics display and 15 memories for drying programs

Certificate : without Certificate
Hurry! only 9 items left in stock.
€1,080.00
€1,200.00
Save 10%
Tax excluded
Quantity

Add to Compare
Add to Wishlist

KERN DAB 200-2 Moisture analyser with user-friendly graphics display and 15 memories for drying programs

  • Backlit LCD display, digit height 14 mm
    • Drying process active
    • Active heating profile
    • Active switch-off criteria
    • Previous drying time
    • Current temperature
    • Unit of the shown result, e.g. moisture [%]
    • Interim result in moisture-%
  • Halogen quartz glass heater 400 W
  • Observation window above the sample, useful during initial setting
  • Internal memory for automatic sequence of 15 complete drying processesand 5 drying processes carried out
  • The last value measured remains on the display until it is replaced by a new measurement
  • 50 sample plates included
  • Application handbook: On the internet, you will find a practical application handbook containing many examples, field reports, settings and tips for each KERN moisture analyser
FEATURES
  • Adjusting program (CAL): For quick setting of the balance's accuracy. External adjusting weight required.
  • Memory: Balance contains memories, e.g. for tare weights, weighing data, item data, PLU etc.
  • Data interface RS-232: To connect the balance to a printer, PC or network
  • GLP/ISO log: with weight, date and time. Only with KERN printers, see Accessories
  • Weighing units: Can be switched to e.g. nonmetric units at the touch of a key. See balance model.
  • Mains part: mains part integrated in the balance. 230V/50Hz Standard type D
  • Strain gauge: An electrical resistor strip that is glued to an elastic deforming body made of aluminium. As the strain gauge is mechanically deformed its resistance value changes, allowing
  • 3 years warranty
OPTIONS
  • Calibration certificate possible. The time required for calibration is 3-4 days
Technical data:
  • Level indicator
  • Material weighing plate: Aluminium dish
  • Overall dimensions mounted (WxDxH): 240 mm x 365 mm x 180 mm
  • Revolving screw feet
  • Weighing surface (d): 92 mm
  • Gross weight: 6,100 kg
  • Net weight: 4,820 kg
Display
  • Display digit height: 14 mm
  • Display digit height: 6 mm
Power supply
  • Input voltage: 230 V AC 50 Hz
Measuring system
  • External calibration
  • Linearity: 0,01g
  • Measuring range [Max]: 199 °C
  • Readout [d]: 0,01 g
  • Reproducibility: 1 mg
  • Resolution: 200000
  • Stabilisation time: 3 s
  • Tare range: 200 g
  • Warm up time: 2 h
  • Weighing range [Max]: 200 g
  • Weighing system: Strain gauge
  • Weighing units: % Feuchte % Trockenmasse g
Environmental conditions
  • Maximum humidity: 80 %
  • Maximum operating temperature: 40 °C
  • Minimum ambient temperature: 5 °C
  • Minimum humidity: 5 %
: DAB 200-2
Hurry! only 9 items left in stock.

Data sheet

Readout [d]
0,01 g / 0,10 %
Reproducibility
0,01 g / 0,10 %
Weighing plate dimensions
Ø 92 mm
Net weight
4,9 kg
Weighing range [Max]
200 g
